Mobile Acoustic Partition Wall Floor To Ceiling Sliding Partitions For Classroom
Movable acoustic partition walls offer a sophisticated and flexible solution for dividing spaces while complementing the architectural design of any environment. These partitions consist of multiple individual panels that glide effortlessly along a horizontal ceiling-mounted track, eliminating the need for floor guides. The panels are easy to handle, install, and adjust, ensuring a safe and efficient operation. The primary benefit of soundproof sliding walls lies in their space-saving design: they occupy minimal space when retracted and provide a complete, seamless wall when fully assembled.
Features:
Flexible Adjustment: Easily expand or retract the partition to meet varying needs with minimal effort.
Efficient Storage: Designed for convenient preservation and storage, making it practical for any space.
Superior Insulation: Provides excellent soundproofing and thermal insulation, enhancing comfort and privacy.
Modern Design: Stylish and contemporary, it seamlessly integrates into any setting while adding a decorative touch.
Robust Stability: Engineered for stability, ensuring the partition remains securely in place without shifting.
Roller Option & Feature
1. Dupont POM roller
2. 304 stainless steel heavy duty roller with safety device & CNC machining
3. Unique and patented wheel surface and shape make the whole movable partition easy to use
Panel Option & Feature
1. Thickness: 68mm & 89mm & 105mm
2. Wide variety of acoustical and decorative finishes available
3. 6061-T6 profile and inside Q235 steel frame for superior durability
4 Top & bottom jack lifting mechanism seal are with power of 800N. Magnetic seal in concave & convex profile has magnetic attraction of 40N/m.
SPECIFICATION:
| GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS |
| | Dimensions in mm* | Design |
| Series | Element thickness | Element width* (min./max.) | Clear height* (min./max.) | Framed construction | Panel fixing | Element interconnection/design of
the vertical profiles |
| AE65 | 68 | 600/1,250 | 2,000/4,500 | Aluminium-steel | Freely oscillating | Aluminium profile
with magnetic strip
and sealing lips |
| AE85 | 89 | 600/1,250 | 2,000/5,500 | Aluminium-steel | Freely oscillating | Aluminium profile
with magnetic strip
and sealing lips |
| AE100 | 105 | 600/1,250 | 2,000/18,000 | Aluminium-steel | Freely oscillating | Aluminium profile
with magnetic strip
and sealing lips |
Technology:
Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56
Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m
* Larger widths possible on application. Provisional details regarding the element heights/element
widths indicated can only be confirmed following consultation with the Design Department.
** Depending on the sound insulation/weight |
